Land Rover Range Rover III facelift 2 (2009-2012) command select wiring diagram
This page shows the only wiring diagram for the component.command select, which is found in the car Land Rover Range Rover III facelift 2 (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
command select wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
COMMAND SELECT
ENGINE JUNCTION BOX
FUSE 9
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERLOCK SOLENOID
MANUAL SPORT DISPLAY ILLUMINATION
P LK CONFIRMATION
PARK LOCK SOLENOID (UNDER CENTER CONSOLE)
PPL
PPL/YEL WIRE
RED WIRE
SHIFT COMMAND SWITCH
SHIFT LOCK
SHIFTLOCK -
SHIFTLOCK+/ KEYLOCK+
SPORT/ MANUAL
STEP
TRANSMISSION CONTROL MODULE TCM, BODY CONTROL VALVE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> COMMAND SELECT
