Starting circuit, w/ tss for Land Rover Range Rover Sport L494 (2013-2017)

AUTOMATIC TRANSMISSION SWITCH AUXILIARY JUNCTION BOX BATTERY BATTERY JUNCTION BOX 2 BATTERY MONITORING SYSTEM MODULE BLK WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/PPL WIRE CENTER REAR OF LUGGAGE COMPT) CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DIP ENGINE CONTROL MODULE (ECM) FUSIBLE LINK 1 FUSIBLE LINK 2 FUSIBLE LINK 5 GRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BLU WIRE GRY/ORG WIRE HS CAN-H HS CAN-L HSD I S TNSW MEGA FUSE NCA WIRE O S STRPH O S STRPL O S STRTH O S STRTL P/N SIG POWER DISTRIBUTION SYSTEM PPL/ORG WIRE RED WIRE RIGHT END OF DASH) STARTER MEGA FUSE STOP/START SWITCH THROUGH PANEL STUD TRANSIT RELAY (ON BATTERY) YEL WIRE YEL/ORG WIRE

BLK WIRE BRN/BLU WIRE CABLE JUNCTION STUD ENGINE JUNCTION BOX FUSE 14 FUSIBLE LINK 15 FUSIBLE LINK 3 GENERATOR GRY/ORG WIRE MOTOR ORG/GRN WIRE PINION PPL/ORG WIRE RED WIRE RED/BLK WIRE STARTER MOTOR STARTER MOTOR RELAY STARTER PINION RELAY YEL WIRE
