Land Rover Range Rover Sport L494 (2013-2017) deployable side step control module Wiring diagram
This page shows the only wiring diagram for the component.deployable side step control module, which is found in the car Land Rover Range Rover Sport L494 (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram deployable side step control module (1 of 1)
AUX SW
AUXILIARY LIGHTING SWITCH
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DEPLOY
DEPLOYABLE SIDE STEP CONTROL MODULE
FUSE 25
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HALL SENSOR LH
HALL SENSOR RH
HALL SENSOR+VE
HALL SENSOR-VE
HOT AT ALL TIMES
INHIBIT SW
INHIBIT SWITCH
LEFT DEPLOYABLE SIDE STEP ILLUMINATION
LEFT DEPLOYABLE SIDE STEP MOTOR
LH DEPLOY
LH STOW
MS CAN +
MS CAN-H
MS CAN-L
POS SENSE +
PPL/GRY WIRE
PPL/RED WIRE
PWR
REAR JUNCTION BOX
RH DEPLOY
RH STOW
RIGHT DEPLOYABLE SIDE STEP ILLUMINATION
RIGHT DEPLOYABLE SIDE STEP MOTOR
RIGHT END OF DASH)
RTN
SENSE
SENSE GND
STATUS LED
STOW
SWITCH ILLUMINATION
VBATT
WHT WIRE
YEL/ORG WIRE
YEL/PPL WIRE
Go to component -> Retractable running boards circuit -> DEPLOYABLE SIDE STEP CONTROL MODULE
