Land Rover Range Rover Sport L320 (2009-2013) Electronic damper control circuit

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE COMPUTER DATA LINES SYSTEM CONTINUOUSLY VARIABLE DAMPER MODULE DAMPER FL NEG DAMPER FL POS DAMPER FR NEG DAMPER FR POS DAMPER RL NEG DAMPER RL POS DAMPER RR NEG DAMPER RR POS ENGINE JUNCTION BOX FRONT ACCELEROMETER FUSE 7 HOT W/ ENGINE CONTROL MODULE RELAY ENERGIZED HS CAN-H HS CAN-L LEFT FRONT DAMPER SOLENOID LEFT FRONT HEIGHT SENSOR LEFT REAR ACCELEROMETER LEFT REAR DAMPER SOLENOID LEFT REAR HEIGHT SENSOR PO FL SIG PO FR SIG PO RL SIG PO RR SIG PPL/ORG WIRE RED/WHT WIRE RIGHT FRONT DAMPER SOLENOID RIGHT FRONT HEIGHT SENSOR RIGHT REAR ACCELEROMETER RIGHT REAR DAMPER SOLENOID RIGHT REAR HEIGHT SENSOR SENS GND SENS SUPPLY SENS SUPPLY 2 SENSOR GND 1 SENSOR GND 2 SENSOR SUPP 1 SUPPLY VA FRONT SIG VA RL SIG VA RR SIG VA SIG WHT/RED WIRE YEL/BLK WIRE YEL/BRN WIRE
