Car Wiring Diagrams for Tire pressure monitoring circuit for Land Rover Range Rover Sport II (2013-2017)

BLK WIRE BLU/BRN WIRE BLU/ORG WIRE BODY CONTROL MODULE (BCM) BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX COMM COMPUTER DATA LINES SYSTEM FUSE 1 GRN/ORG WIRE GRY/BLU WIRE GRY/PPL WIRE GRY/RED WIRE HOT AT ALL TIMES HS CAN L LR+ HS CAN-H LEFT FRONT INITIATOR LEFT REAR INITIATOR LF RR + LF+ PPL/BRN WIRE RED WIRE RF RX RF+ RF- COMM RIGHT END OF DASH) RIGHT FRONT INITIATOR RIGHT REAR INITIATOR RR + LR + TIRE PRESSURE MONITORING SYSTEM (TPMS) RECEIVER YEL WIRE
