Passenger"s memory seat circuit, 8-way for Land Rover Range Rover Sport II (2013-2017)

BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BOLSTER DEF BOLSTER INF BRN/BLU WIRE BRN/GRN WIRE BRN/PPL WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DEFLATE FUSE 17 FUSE 8 GRN/PPL WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/PPL WIRE GRY/YEL WIRE HEIGHT MTR DOWN HEIGHT MTR SENS HEIGHT MTR UP HEIGHT SENSE GND HOT AT ALL TIMES HOT W/ COMFORT RELAY ENERGIZED INFLATE LOGIC FEED LOGIC GND LUMBAR DWN LUMBAR FWD LUMBAR PUMP LUMBAR RWD LUMBAR UP MASSAGE MASTER SOLENOID MEMORY IN MEMORY OUT MS CAN-H MS CAN-L PASSENGER LUMBAR SOLENOIDS PASSENGER SEAT BOLSTER SOLENOID PASSENGER SEAT MEMORY SWITCHPACK PASSENGER SEAT MODULE PASSENGER SEAT SWITCHPACK POWER FEED 1 POWER GND 1 PPL PPL/GRN WIRE PPL/WHT WIRE REAR JUNCTION BOX RED WIRE SLIDE MTR (FWD) SLIDE MTR RWD SLIDE MTR SENS SLIDE SENSE GND SQUAB MTR INCLINE SQUAB MTR RECLINE SQUAB MTR SNS SQUAB SENSE GND STATUS IN STATUS OUT SWITCH ILLUM. TILT MTR DOWN TILT MTR SENS TILT MTR UP TILT SENCE GND VBATT WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/PPL WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/PPL WIRE

BLK WIRE BLU/GRN WIRE BLU/GRY WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/PPL WIRE BRN/WHT WIRE GRN/PPL WIRE GRY/BLU WIRE HALL EFFECT SENSOR PASSENGER LUMBAR PUMP PASSENGER SEAT BACKREST RECLINE MOTOR PASSENGER SEAT FORWARD REARWARD MOTOR PASSENGER SEAT HEIGHT MOTOR PASSENGER SEAT TILT MOTOR PPL PPL/GRN WIRE PPL/WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE YEL/GRN WIRE
