Land Rover Range Rover Sport II (2013-2017) Driver"s memory seat circuit, 8-way

BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BOLSTER DEF BOLSTER INF BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/PPL WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DEFLATE DRIVER LUMBAR SOLENOIDS DRIVER SEAT BOLSTER SOLENOID DRIVER SEAT MEMORY SWITCHPACK DRIVER SEAT MODULE DRIVER SEAT SWITCHPACK FUSE 42 FUSE 8 GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/PPL WIRE GRY/YEL WIRE HEIGHT MTR DOWN HEIGHT MTR SENS HEIGHT MTR UP HEIGHT SENSE GND HOT AT ALL TIMES HOT W/ COMFORT RELAY ENERGIZED INFLATE LEFT REAR FOOTWELL LOGIC FEED LOGIC GND LUMBAR DWN LUMBAR FWD LUMBAR PUMP LUMBAR RWD LUMBAR UP MASSAGE MASTER SOLENOID MEMORY IN MEMORY OUT MS CAN-H MS CAN-L POWER FEED 1 POWER GND 1 PPL PPL/GRN WIRE PPL/GRY WIRE PPL/ORG WIRE REAR JUNCTION BOX RIGHT END OF DASH) SLIDE MTR (FWD) SLIDE MTR RWD SLIDE MTR SENS SLIDE SENSE GND SQUAB MTR INCLINE SQUAB MTR RECLINE SQUAB MTR SNS SQUAB SENSE GND STATUS IN STATUS OUT SWITCH ILLUM. TILT MTR DOWN TILT MTR SENS TILT MTR UP TILT SENS GND UPPER CELL VBATT WHT/GRN WIRE YEL WIRE YEL/ORG WIRE YEL/PPL WIRE YEL/RED WIRE

BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/YEL WIRE DRIVER LUMBAR PUMP DRIVER SEAT FORWARD/REARWARD MOTOR DRIVER SEAT HEIGHT MOTOR DRIVER SEAT TILT MOTOR GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/WHT WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HALL EFFECT SENSOR LEFT REAR FOOTWELL PPL/GRY WIRE PPL/ORG WIRE RECLINE SEAT BACKREST MOTOR YEL/ORG WIRE YEL/PPL WIRE
