Land Rover Range Rover Sport II (2013-2017) w/o transit relay w/ transit relay w/ tss w/o tss Wiring diagram

ABS MODULE AUDIO AMPLIFIER MODULE AUXILIARY JUNCTION BOX BATTERY BATTERY JUNCTION BOX BATTERY JUNCTION BOX 2 BATTERY MONITORING SYSTEM MODULE BLK WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BRN WIRE CABLE JUNCTION STUD CBDCBB ENGINE JUNCTION BOX FROM QUIESCENT CURRENT CONTROL MODULE (QCCM) (DIAGRAM 9 OF 9) FRONT ELECTRIC COOLING FAN FUSE 15 FUSIBLE LINK 1 FUSIBLE LINK 11 FUSIBLE LINK 2 FUSIBLE LINK 3 FUSIBLE LINK 4 FUSIBLE LINK 5 FUSIBLE LINK 6 FUSIBLE LINK 7 FUSIBLE LINK 8 FUSIBLE WIRE LINK GENERATOR GRN WIRE GRY/ORG WIRE MEGA FUSE MEGA FUSE 2 NCA WIRE POWER STEERING CONTROL MODULE POWER SUPPLY DISTRIBUTION BOX PTC 1 RELAY PTC 2 RELAY RED WIRE RED/BLK WIRE RED/YEL WIRE SECONDARY BATTERY STARTER MEGA FUSE STARTER MOTOR STARTER MOTOR RELAY STARTER PINION RELAY TERMINAL JUMP START THROUGH PANEL STUD TO CENTRAL JUNCTION BOX (DIAGRAM 2 OF 9) TO CENTRAL JUNCTION BOX (DIAGRAM 3 OF 9) TO CENTRAL JUNCTION BOX (DIAGRAM 5 OF 9) TO CENTRAL JUNCTION BOX (DIAGRAM 6 OF 9) TO FUSIBLE LINK 8 (DIAGRAM 2 OF 9) TO REAR JUNCTION BOX (DIAGRAM 7 OF 9) TRANSIT RELAY W/O TRANSIT RELAY W/ TRANSIT RELAY W/ TSS W/O TSS YEL/RED WIRE
