Land Rover Range Rover Sport II (2013-2017) tail led array Wiring diagram
This page shows the only wiring diagram for the component.tail led array, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tail led array (1 of 1)
BACKUP LAMPS CIRCUIT
BLK WIRE
BODY CONTROL MODULE (BCM)
BRN/RED WIRE
CENTRAL JUNCTION BOX
CHMSL PWR
COMPUTER DATA LINES SYSTEM
DI LED ARRAY
DRIVER DOOR MODULE
DRIVER SIDE DOOR MIRROR
FUSE 14
FUSE 32
FUSE 58
GRN/BRN WIRE
GRN/ORG WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/PPL WIRE
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
HOT W/ EXTENDED IGNITION RELAY ENERGIZED
LEFT LAMP
LEFT TAILLAMP ASSEMBLY
LH DI CHSML REAR
LH STOP LAMP
LICENSE PLATE, TAIL DOOR SWITCH
MIRR GND
MIRR SPLY
MIRROR DI
MS CAN-H
MS CAN-L
PASSENGER DOOR MODULE
PASSENGER SIDE DOOR MIRROR
POSI LMP RR LH
POSI LMP RR RH
PPL/GRN WIRE
PPL/ORG WIRE
PPL/RED WIRE
REAR JUNCTION BOX
REAR VIEW MIRROR)
REVERSE LED ARRAY
RF FILTER
RH DI FRONT
RH DI REAR
RH STOP LAMP
RIGHT END OF DASH)
RIGHT LAMP
RIGHT TAILLAMP ASSEMBLY
SIDE REPEATER
SIDE REPEATER IND
STOP LED ARRAY
TAIL LED ARRAY
VBATT
WHT/ORG WIRE
YEL/GRY WIRE
YEL/PPL WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> TAIL LED ARRAY
