Land Rover Range Rover Sport II (2013-2017) stop start switch Wiring diagram
This page shows the only wiring diagram for the component.stop start switch, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop start switch (1 of 1)
BATTERY SAVER RELAY
BLK WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BRN/GRN WIRE
BRN/PPL WIRE
BRN/YEL WIRE
COMFORT RLY HSD
DRIVER DOOR POCKET AMBIANCE LIGHTING
FLOOR CONSOLE TRAY ILLUMINATION
FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 9)
FRONT OVERHEAD CONSOLE
FUSE 23
FUSE 49
FUSE 50
FUSE 57
GLOVE BOX ILLUMINATION LAMP
GRN/WHT WIRE
HUMIDITY SENSOR
LEFT HEADLAMP
LEFT INNER FLOOR CONSOLE AMBIANCE LIGHTING
LEFT OUTER FLOOR CONSOLE AMBIANCE LIGHTING
LEFT REAR DOOR POCKET AMBIANCE LIGHTING
LEFT REAR INTERIOR LAMP
LEFT VANITY MIRROR
PASSENGER DOOR POCKET AMBIANCE LIGHTING
PPL/BRN WIRE
PPL/GRY WIRE
RED WIRE
RIGHT HEADLAMP
RIGHT INNER FLOOR CONSOLE AMBIANCE LIGHTING
RIGHT OUTER FLOOR CONSOLE AMBIANCE LIGHTING
RIGHT REAR DOOR POCKET AMBIANCE LIGHTING
RIGHT REAR INTERIOR LAMP
RIGHT VANITY MIRROR
STOP START SWITCH
TO REAR JUNCTION BOX (DIAGRAM 8 OF 9)
TO REAR JUNCTION BOX (DIAGRAM 9 OF 9)
TRAILER SOCKET RELAY
YEL/ORG WIRE
Go to component -> Power distribution circuit (6 of 9) -> STOP START SWITCH
