Land Rover Range Rover Sport II (2013-2017) r hldr lvds neg ppl r hldr lvds pos scr r hldr lvds scr Wiring diagram
This page shows the only wiring diagram for the component.r hldr lvds neg ppl r hldr lvds pos scr r hldr lvds scr, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram r hldr lvds neg ppl r hldr lvds pos scr r hldr lvds scr (1 of 1)
AUDIO GND
AUDIO L+
AUDIO R-
AUX AUDIO IN GND
AUX AUDIO IN LEFT +
AUX AUDIO IN RIGHT +
AUX PANEL VIDEO GND
AUX PANEL VIDEO IN
AUX USB DATA NEG
AUX USB DATA POS
AUX USB DATA SHIELD
AUX USB GND
AUX USB GND SCR AUX USB SHIELD
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CVBS VIDEO IN
CVBS VIDEO IN GND
CVBS VIDEO OUT
CVBS VIDEO OUT GND
FUSE 6
GRN WIRE
GRY/RED WIRE
HLDR GND
HOT W/ MICRO RELAY 1 ENERGIZED
L HLDR LVDS NEG PPL L HLDR LVDS POS SCR L HLDR LVDS SCR
MOST IN
MOST OUT
MS CAN NEG
MS CAN POS
NCA WIRE
ORG/ WIRE
PPL
QUIESCENT CURRENT CONTROL MODULE
R HLDR LVDS NEG PPL R HLDR LVDS POS SCR R HLDR LVDS SCR
REAR CONSOLE PORTABLE DEVICE INTERFACE
REAR SEAT ENTERTAINMENT MODULE
RED WIRE
SUPPLY
TV LVDS NEG
TV LVDS POS SCR
VBATT
VIDEO OUT
VIDEO OUT GND
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Rear seat entertainment circuit (1 of 3) -> R HLDR LVDS NEG PPL R HLDR LVDS POS SCR R HLDR LVDS SCR
