Land Rover Range Rover Sport II (2013-2017) piston side front actuator pressure regulating valve Wiring diagram

ACTUATOR PRESSURE SENSOR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/PPL WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DYNAMIC RESPONSE CONTROL MODULE DYNAMIC RESPONSE VALVE BLOCK ENGINE JUNCTION BOX FAPRVPISTN NEG FAPRVPISTN POS FAPRVROD NEG FAPRVROD POS FAPSNSPISTN GND FAPSNSPISTN SIG FAPSNSROD GND FAPSNSROD SIG FUSE 12 FUSE 17 GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN H (CH) HS CAN H (PT) HS CAN L (CH) RAPSNSPISTN SIG HS CAN L (PT) IGN LATACCLWR GND LATACCLWR SIG LATACCUPR GND LATACCUPR SIG LOWER ACCELEROMETER PCV NEG PCV POS PCVPSNS GND PCVPSNS SIG PISTON SIDE FRONT PISTON SIDE FRONT ACTUATOR PRESSURE REGULATING VALVE PISTON SIDE REAR PISTON SIDE REAR ACTUATOR PRESSURE REGULATING VALVE PPL PPL/BRN WIRE PPL/GRN WIRE PPL/RED WIRE PRESSURE CONTROL VALVE PRESSURE CONTROL VALVE PRESSURE SENSOR RAPRVPISTN NEG RAPRVPISTN POS RAPRVROD NEG RAPRVROD POS RAPSNDROD SIG RAPSNSPISTN GND RAPSNSROD GND ROD SIDE FRONT ROD SIDE FRONT ACTUATOR PRESSURE REGULATING VALVE ROD SIDE REAR ROD SIDE REAR ACTUATOR PRESSURE REGULATING VALVE SAFETY CONTROL VALVE SCV NEG SCV POS UPPER ACCELEROMETER VBATT WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/PPL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
