Land Rover Range Rover Sport II (2013-2017) logic pwr Wiring diagrams

AUTOMATIC TRANSMISSION SWITCH BLK WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE BRN/RED WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM CRANK REQUEST DOWN DOWN ILLUM DOWNSHIFT PADDLE SWITCH ENGINE CONTROL MODULE ENGINE JUNCTION BOX FUSE 22 FUSE 30 FUSE 51 GRN WIRE GRN/ORG WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED HS CAN-H HS CAN-L I S TNSW IGN ILLUM INSTRUMENT CLUSTER LEFT STEERING WHEEL SWITCHPACK LOGIC GND LOGIC PWR P-SIGNAL P/N SIG PADDLE DOWN PADDLE UP PARK/ NEUT SIG RED WIRE RIGHT END OF DASH) RIGHT STEERING WHEEL SWITCHPACK TCMP TERRAIN RESPONSE SWITCHPACK TRANSMISSION CONTROL MODULE UP ILLUM UPSHIFT PADDLE SWITCH VBATT WHT/BRN WIRE YEL WIRE

ADAPTIVE SPEED CONTROL MODULE BCM LIN BLK WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BODY CONTROL MODULE BRAKE DIAG SW BRAKE SW SIG BRN WIRE BRN/RED WIRE BRN/WHT WIRE CANCEL/ON SWITCH CENTRAL JUNCTION BOX CLOCK- SPRING COMPUTER DATA LINES SYSTEM ENGINE JUNCTION BOX FUSE 12 FUSE 14 FUSE 16 FUSE 19 FUSE 51 GRN/ORG WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ EXTENDED IGNITION RELAY ENERGIZED HOT W/ IGNITION RELAY ENERGIZED HS CAN-H HS CAN-L IGN INSTRUMENT CLUSTER LEFT STEERING WHEEL SWITCHPACK LIN 1 LOGIC GND LOGIC PWR NCA WIRE ORG/ WIRE PPL PPL/BRN WIRE PPL/ORG WIRE REAR JUNCTION BOX RED WIRE RESUME + SWITCH RIGHT END OF DASH) RIGHT STEERING WHEEL SWITCHPACK SET SWITCH STEERING WHEEL HEATER STEERING WHEEL HEATER CONTROL MODULE STEERING WHEEL MODULE TRANSMISSION CONTROL MODULE (TCM) WHT WIRE WHT/PPL WIRE

BLK WIRE CENTRAL JUNCTION BOX CLOCK- SPRING COMPUTER DATA LINES SYSTEM DOWNSHIFT PADDLE SWITCH DRIVER DOOR HANDLE AMBIENCE LIGHTING FUSE 39 FUSE 44 FUSE 51 GND ILLUM HOT AT ALL TIMES ILLUM LEFT REAR DOOR HANDLE AMBIENCE LIGHTING LEFT REAR DOOR MODULE LEFT REAR FOOTWELL LEFT REAR WINDOW SWITCH LEFT STEERING WHEEL SWITCHPACK LOGIC GND LOGIC PWR MS CAN-H MS CAN-L NCA WIRE PADDLE DOWN GND PADDLE DOWN ILLUM PADDLE UP ILLUM PASSENGER DOOR HANDLE AMBIENCE LIGHTING PASSENGER DOOR MODULE PASSENGER DOOR WINDOW SWITCH RED WIRE RIGHT END OF DASH) RIGHT REAR DOOR HANDLE AMBIENCE LIGHTING RIGHT REAR DOOR MODULE RIGHT REAR WINDOW SWITCH RIGHT STEERING WHEEL SWITCHPACK SEATS SYSTEM STATUS ILLUM STEERING WHEEL MODULE SWITCH GND UPSHIFT PADDLE SWITCH V BATT VBATT YEL WIRE
