Land Rover Range Rover Sport II (2013-2017) logic power Wiring diagram
This page shows the only wiring diagram for the component.logic power, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram logic power (1 of 1)
BCM LIN
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
CENTRAL JUNCTION BOX
CLOCK- SPRING
COMPUTER DATA LINES SYSTEM
ECU OUTPUT
EJC OUTPUT
FUSE 20
FUSE 51
GRN/ORG WIRE
HC POWER
HI CURRENT GND
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
HS CAN-H
HS CAN-L
HTR SWITCH
LED ENABLE
LEFT STEERING WHEEL SWITCHPACK
LIN 1
LOGIC GND
LOGIC POWER
NCA WIRE
NTC-
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT END OF DASH)
RIGHT STEERING WHEEL SWITCHPACK
STEERING WHEEL HEATER
STEERING WHEEL HEATER CONTROL MODULE
STEERING WHEEL HEATER SWITCH
STEERING WHEEL MODULE
STEERING WHEEL TEMPERATURE SENSOR
WHT WIRE
YEL/PPL WIRE
Go to component -> Heated steering wheel circuit -> LOGIC POWER
