Land Rover Range Rover Sport II (2013-2017) left outboard third row buckle switch wiring diagram
This page shows the only wiring diagram for the component.left outboard third row buckle switch, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left outboard third row buckle switch wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTER REAR SEAT BELT SWITCH
DRIVER ANCHOR SEAT BELT PRETENSIONER
DRIVER BUCKLE SWITCH
DRIVER SEAT POSITION SENSOR
DRIVER SIDE AIR BAG
FRONT OVERHEAD CONSOLE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
GRY/PPL WIRE
GRY/YEL WIRE
LEFT FRONT DOOR IMPACT PRESSURE SENSOR
LEFT INBOARD THIRD ROW BUCKLE SWITCH
LEFT OUTBOARD THIRD ROW BUCKLE SWITCH
LEFT SIDE AIR CURTAIN
PASSENGER AIR BAG DISABLE INDICATOR
PASSENGER BUCKLE SWITCH
PASSENGER LOAD LIMITER SEAT BELT RETRACTOR
PASSENGER SEAT POSITION SENSOR
PASSENGER SIDE AIR BAG
PPL/GRY WIRE
PWR
RIGHT FRONT DOOR IMPACT PRESSURE SENSOR
RIGHT INBOARD THIRD ROW BUCKLE SWITCH
RIGHT OUTBOARD THIRD ROW BUCKLE SWITCH
RIGHT SIDE AIR CURTAIN
RTN
SIG
SQUIB PWR
SQUIB RTN
WHT/PPL WIRE
YEL WIRE
YEL/ORG WIRE
YEL/PPL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> LEFT OUTBOARD THIRD ROW BUCKLE SWITCH
