Land Rover Range Rover Sport II (2013-2017) left deployable sidestep illumination wiring diagram
This page shows the only wiring diagram for the component.left deployable sidestep illumination, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left deployable sidestep illumination wiring diagram (1 of 1)
AM/FM ANTENNA AMPLIFIER SHIELD
AUTOMATIC TRANSMISSION SWITCH
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
DEPLOYABLE SIDESTEP CONTROL MODULE
DIGITAL RADIO CONTROL MODULE SHIELD
ELECTRIC BOOSTER HEATER
ELECTRIC PARK BRAKE CONTROL MODULE
EXHAUST ACTUATOR VALVE
FM ANTENNA AMPLIFIER SHIELD
FRONT CIGAR LIGHTER
INTEGRATED AUDIO MODULE SHIELD
INTEGRATED SUSPENSION CONTROL MODULE
LEFT DEPLOYABLE SIDESTEP ILLUMINATION
LEFT INNER FLOOR CONSOLE AMBIENCE LIGHTING LED
LEFT OUTER FLOOR CONSOLE AMBIENCE LIGHTING LED
NCA WIRE
POWER SUPPLY DISTRIBUTION BOX
REAR DIFFERENTIAL CONTROL MODULE
REAR JUNCTION BOX
RESPONSE TERRAIN SWITCHPACK
RIGHT DEPLOYABLE SIDESTEP ILLUMINATION
RIGHT INNER FLOOR CONSOLE AMBIENCE LIGHTING LED
RIGHT OUTER FLOOR CONSOLE AMBIENCE LIGHTING LED
SECONDARY BATTERY
TRANSFER CASE CONTROL MODULE
TRANSIT RELAY
TRANSMISSION CONTROL MODULE
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 8) -> LEFT DEPLOYABLE SIDESTEP ILLUMINATION
