Land Rover Range Rover Sport II (2013-2017) global close tailgate switch Wiring diagram
This page shows the only wiring diagram for the component.global close tailgate switch, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram global close tailgate switch (1 of 1)
AUXILIARY CLIMATE CONTROL TEMPERATURE BLEND MOTOR
BLK WIRE
BLOWER CONTROL MODULE
DEPLOYABLE TOWBAR CONTROL MODULE
GLOBAL CLOSE TAILGATE SWITCH
HEATED REAR WINDOW ELEMENT
HIGH MOUNTED STOP LAMP
IMAGE PROCESSING MODULE
LEFT "C" PILLAR)
LEFT AUXILIARY TEMPERATURE BLEND MOTOR
LEFT INBOARD THIRD ROW BUCKLE SWITCH
LEFT REAR FOG LAMP
LEFT REAR INTERIOR LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT TAILGATE LAMP
LEFT VANITY MIRROR
MAGNETIC VALVE
POWERED TAILGATE MODULE
REAR BLOWER
REAR VIEW CAMERA
REAR WINDOW WIPER MOTOR
RF FILTER
RIGHT AUXILIARY TEMPERATURE BLEND MOTOR
RIGHT INBOARD THIRD ROW BUCKLE SWITCH
RIGHT REAR FOG LAMP
RIGHT REAR INTERIOR LAMP
RIGHT TAIL LAMP ASSEMBLY
RIGHT TAILGATE LAMP
RIGHT VANITY MIRROR
SELF- LEVELING SUSPENSION COMPRESSOR
TAIL DOOR SWITCH, LICENSE PLATE LAMP
TAILGATE CLOSING MOTOR
TAILGATE LATCH
TRAILER PICK-UP (7 PIN)
W/ POWERED TAILGATE
WHT WIRE
Go to component -> Ground distribution circuit (4 of 8) -> GLOBAL CLOSE TAILGATE SWITCH
