Land Rover Range Rover Sport II (2013-2017) driver approach lamp Wiring diagram
This page shows the only wiring diagram for the component.driver approach lamp, which is found in the car Land Rover Range Rover Sport II (2013-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver approach lamp (1 of 1)
AJAR SWITCH
APPROACH
BATTERY JUNCTION BOX
BLK WIRE
BLU WIRE
BRN WIRE
CLOSE GLOBAL TAILGATE SWITCH
COMPUTER DATA LINES SYSTEM
DRIVER APPROACH LAMP
DRIVER CENTRAL DOOR LOCKING MOTOR
DRIVER DOOR MODULE
DRIVER SIDE DOOR MIRROR
FUSIBLE LINK 6
FUSIBLE LINK 7
GRN WIRE
GRY/PPL WIRE
HOT AT ALL TIMES
ILLUM
LATCH GND
LEFT REAR CENTRAL DOOR LOCKING MOTOR
LEFT REAR DOOR MODULE
LEFT REAR FOOTWELL
LEFT REAR TREAD PLATE ILLUMINATION
LEFT TAILGATE LAMP
LUGGAGE COMPARTMENT LAMP
MIRROR GND
MS CAN-H
MS CAN-L
PASSENGER APPROACH LAMP
PASSENGER CENTRAL DOOR LOCKING MOTOR
PASSENGER DOOR MODULE
PASSENGER SIDE DOOR MIRROR
PPL/RED WIRE
RIGHT REAR CENTRAL DOOR LOCKING MOTOR
RIGHT REAR DOOR MODULE
RIGHT REAR TREAD PLATE ILLUMINATION
RIGHT TAILGATE LAMP
VBATT
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> DRIVER APPROACH LAMP
