Telematics circuit, convertible for Land Rover Range Rover Evoque L538 (2015-2019)

B-CALL ACTIVATED LED B-CALL BACKLIGHT B-CALL BTN BACKLIGHT B-CALL LED 1 BEHIND LEFT QUARTERPANEL) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/YEL WIRE BTN DIAGNOSTIC BTN INPUT COMMON BTN SW RTN BTN'S DIAGNOSTIC O/P COMPUTER DATA LINES SYSTEM CRASH SIG E-CALL BACKLIGHT E-CALL BTN BACKLIGHT E-CALL LED 1 ECALL ACTIVATED LED ECALL/BCALL BTN FRONT OVERHEAD CONSOLE FUSE 7 GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE HOT AT ALL TIMES HS CAN-H HS CAN-L INFOTAINMENT MASTER CONTROLLER (IMC) LED 2 LED O/P COMM MIC - MIC 1 GND MIC 1+ MIC OUT + MIC OUT SCR MIC SCR MICROPHONE MS CAN-H MS CAN-L NCA WIRE ORG/ WIRE REAR JUNCTION BOX RED WIRE SCR SCR BR SHIELD SOUND SYSTEMS SPEAKER SUPPLEMENTAL RESTRAINTS SYSTEM TCU BR SHIELD TCU LED RTN TELEMATIC CONTROL MODULE TELEMATICS SPEAKER WHT WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/PPL WIRE

BLK WIRE BLU WIRE DATA DIAGNOSTICS 1 DIAGNOSTICS 2 GND SCR SHIELD GPS IN GND GPS IN SIG GPS OUT GND GPS OUT SIG GPS SCR GPS SIG GPS SIGNAL SPLITTER GPS/GNSS SIG GRN WIRE GSM ANTENNA GSM SIG NCA WIRE RED WIRE ROOF POD SCR SCR GND SHIELD TELEMATIC CONTROL MODULE WHT WIRE WIFI WIFI ANTENNA WIFI EXT SCN WIFI EXT SIG WIFI SCR YEL WIRE
