Land Rover Freelander L359 (2012-2014) volumetric sensor Wiring diagrams
This page contains all the electrical diagrams for the component. volumetric sensor, in which he is found in the car Land Rover Freelander L359 (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram volumetric sensor (1 of 3)
AJAR
AJAR SW
ALARM
ANTI THEFT ALARM WARNING IND
BATTERY BACKUP SOUNDER
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN/BLU WIRE
CENTRAL JUNCTION BOX (CJB)
COMPUTER DATA LINES SYSTEM
DI LEFT
DI RIGHT
DRIVER CENTRAL DOOR LOCKING MOTOR
DRIVER DOOR MODULE
DRIVER DOOR SWITCH
ELECTRONIC
FUSE 1
FUSE 17
FUSE 23
FUSE 27
FUSE 36
GND LATCH
GRN WIRE
GRN/ORG WIRE
GRN/PPL WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
HOOD
HOOD SWITCH
HOT AT ALL TIMES
INSTRUMENT CLUSTER
KEYLESS VEHICLE MODULE
LATCH GND
LED
LEFT INDICATOR FET
LEFT REAR CENTRAL DOOR LOCKING MOTOR
LEFT REAR DOOR MODULE
LEFT REAR DOOR SWITCH
MS CAN-H
MS CAN-L
PASSENGER CENTRAL DOOR LOCKING MOTOR
PASSENGER DOOR MODULE
PASSENGER DOOR SWITCH
PPL/ORG WIRE
RADIO FREQUENCY (RF) RECEIVER
RED WIRE
RIGHT INDICATOR FET
RIGHT REAR CENTRAL DOOR LOCK MOTOR
RIGHT REAR DOOR MODULE
RIGHT REAR DOOR SWITCH
RX SERIAL DATA
SUPPLY
TAIL
TAIL DOOR OPEN SWITCH
TAILGATE UPPER CENTRAL DOOR LOCKING MOTOR
VOLUMETRIC SENSOR
WHT WIRE
WHT/PPL WIRE
WHT/RED WIRE
YEL WIRE
YEL/PPL WIRE
Go to component -> Anti-theft circuit, active -> VOLUMETRIC SENSOR
Wiring diagram volumetric sensor (2 of 3)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
DIAGNOSTIC SOCKET
FRONT BLOWER MOTOR CONTROL MODULE
FRONT INTERIOR LAMP
GLOVE BOX ILLUMINATION LAMP
INTEGRATED CONTROL PANEL
LEFT FRONT FOOTWELL LAMP
LEFT VANITY MIRROR
RADIO FREQUENCY RECEIVER
RAIN SENSOR
REAR INTERIOR LAMP
REARVIEW MIRROR)
RIGHT FRONT FOOTWELL LAMP
RIGHT VANITY MIRROR
ROOF OPENING PANEL CONTROL MODULE
SUNROOF SWITCH
TOUCH SCREEN DISPLAY
VOLUMETRIC SENSOR
W/ HIGH LINE
W/ LOW LINE
Go to component -> Ground distribution circuit (5 of 5) -> VOLUMETRIC SENSOR
Wiring diagram volumetric sensor (3 of 3)
ANALOG CLOCK
AUDIO AMPLIFIER MODULE
AUDIO HEAD UNIT
BATTERY BACKED SOUNDER
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRAKE PEDAL SWITCH
BRN/RED WIRE
CLIMATE CONTROL MODULE
DIAGNOSTIC CONNECTOR
DIGITAL RADIO CONTROL MODULE
DRIVER DOOR SWITCHPACK
ELECTRIC PARK BRAKE CONTROL MODULE
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 3 OF 7)
FROM FUSE 51 (DIAGRAM 4 OF 7)
FROM IGNITION RELAY (DIAGRAM 4 OF 7)
FROM VOLTAGE QUALITY MODULE (DIAGRAM 3 OF 7)
FUSE 1
FUSE 14
FUSE 17
FUSE 36
FUSE 40
FUSE 47
FUSE 62
FUSE 66
FUSE LINK 11
GRN/RED WIRE
GRY/ORG WIRE
GRY/RED WIRE
HI LINE
INSTRUMENT CLUSTER
INTEGRATED AUDIO MODULE
INTEGRATED CONTROL PANEL
KEYLESS VEHICLE MODULE
PPL/RED WIRE
REAR JUNCTION BOX (RJB)
RED WIRE
RF RECEIVER
RING BREAK DIAGNOSTIC LINK
ROOF OPENING PANEL CONTROL MODULE
SATELLITE RADIO CONTROL MODULE
TO REAR JUNCTION BOX (RJB) (DIAGRAM 7 OF 7)
TOUCH- SCREEN
VOLUMETRIC SENSOR
W/ START/STOP SYSTEM
W/O START/STOP SYSTEM
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 7) -> VOLUMETRIC SENSOR
