Land Rover Freelander L359 (2012-2014) usb data pos Wiring diagrams
This page contains all the electrical diagrams for the component. usb data pos, in which he is found in the car Land Rover Freelander L359 (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram usb data pos (1 of 3)
+/- +/- DIAG GND
AM FM SCRN
AM FM SIG
AM/FM ANTENNA AMPLIFIER
ANT POWER
AUX 1 L+
AUX 1 R+
AUX 1 R, L-
BLK WIRE
BLK/PPL WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COAX
COMPUTER DATA LINES SYSTEM
CVBS SIG SCR CVBS GND
CVBS VIDEO SIG
CVBS VIDEO SIG SCR CVBS VIDEO SCN
FERRITE CORE
FM ANTENNA AMPLIFIER
GLOBAL POSITIONING SYSTEM (GPS) ANTENNA
GPS SCR
GPS SIG
GRN WIRE
GRY/ORG WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INTEGRATED AUDIO MODULE
INTEGRATED CONTROL PANEL
LVDS DATA OUT +
LVDS NEG PPL LVDS POS SCR LVDS SCR
MIC 1+
MOST IN
MOST OUT
MS CAN-H
MS CAN-L
NCA WIRE
ORG/ WIRE
PPL
PPL/ORG WIRE
REAR JUNCTION BOX (RJB)
REARVIEW CAMERA
RED WIRE
RHS
SCR
SCR GND
SCR GPS SCR
SCR LHS
SWS
TOUCH- SCREEN
USB DATA NEG
USB DATA POS
USB GND
USB POS
USB SHIELD
VBATT
VID OUT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/RED WIRE
Go to component -> Navigation circuit (1 of 4) -> USB DATA POS
