Land Rover Freelander L359 (2012-2014) touch screen display Wiring diagram
This page shows the only wiring diagram for the component.touch screen display, which is found in the car Land Rover Freelander L359 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram touch screen display (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
DIAGNOSTIC SOCKET
FRONT BLOWER MOTOR CONTROL MODULE
FRONT INTERIOR LAMP
GLOVE BOX ILLUMINATION LAMP
INTEGRATED CONTROL PANEL
LEFT FRONT FOOTWELL LAMP
LEFT VANITY MIRROR
RADIO FREQUENCY RECEIVER
RAIN SENSOR
REAR INTERIOR LAMP
REARVIEW MIRROR)
RIGHT FRONT FOOTWELL LAMP
RIGHT VANITY MIRROR
ROOF OPENING PANEL CONTROL MODULE
SUNROOF SWITCH
TOUCH SCREEN DISPLAY
VOLUMETRIC SENSOR
W/ HIGH LINE
W/ LOW LINE
Go to component -> Ground distribution circuit (5 of 5) -> TOUCH SCREEN DISPLAY
