Land Rover Freelander L359 (2010-2012) start req Wiring diagram
This page shows the only wiring diagram for the component.start req, which is found in the car Land Rover Freelander L359 (2010-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram start req (1 of 1)
BATT A
BATTERY
BATTERY JUNCTION BOX
BLK WIRE
BLK/PPL WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/GRN WIRE
CENTRAL ELECTRONICS MODULE (CEM)
CENTRAL JUNCTION BOX
CHARGING CIRCUIT
CLIMATE CONTROL MODULE (BEHIND HEATER CONTROL PANEL)
CLT (P/N)
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM)
FUSE 15
FUSE 27
FUSE 33
FUSE 42
FUSE LINK 17
GRN WIRE
GRN/PPL WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HS CAN-H
HS CAN-L
IGN
IGN COIL
IGN SW
IGNITION RELAY
LED
LIN 3
MS CAN-H
MS CAN-L
NCA WIRE
POWER DISTRIBUTION SYSTEM
PPL/BRN WIRE
PPL/ORG WIRE
RED WIRE
STA-
START CONTROL UNIT
START LOCK
START REQ
START RLY
START/ STOP SWITCH
START/STOP 1
START/STOP 2
STARTER FUSE
STARTER MOTOR
STARTER MOTOR SOLENOID
STARTER RELAY
TRANSMISSION CONTROL MODULE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Starting circuit -> START REQ
