Land Rover Freelander L359 (2010-2012) intrusion detection module Wiring diagrams
This page contains all the electrical diagrams for the component. intrusion detection module, in which he is found in the car Land Rover Freelander L359 (2010-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram intrusion detection module (1 of 4)
Go to component -> Anti-theft circuit (2 of 2) -> INTRUSION DETECTION MODULE
Wiring diagram intrusion detection module (2 of 4)
ABS MODULE
ACTIVE ON DEMAND COUPLING MODULE
BATTERY BACKED SOUNDER (REAR OF ENGINE COMPT)
BLK WIRE
BLU/BRN WIRE
BRN/PPL WIRE
BRN/YEL WIRE
CEM
CENTRAL CONSOLE SWITCH PACK
CENTRAL JUNCTION BOX
ENGINE CONTROL MODULE (TOP CENTER OF FIREWALL)
GEARSHIFT MECHANISM
GENERATOR
GRN/PPL WIRE
GRY/BLU WIRE
GRY/BRN WIRE
HEADLIGHT CONTROL MODULE (IF EQUIPPED) (BEHIND GLOVE BOX)
HS CAN-H
HS CAN-L
INTRUSION DETECTION MODULE
LEFT HEADLAMP
LIGHTING SWITCH MODULE
LIN 0
LIN 1
LIN 2
LIN 3
LIN 7
LIN SCR
ORG/ WIRE
PPL
RADIO FREQUENCY RECEIVER
RAIN SENSOR (TOP CENTER OF WINDSHIELD)
RIGHT HEADLAMP
START CONTROL UNIT
STEERING COLUMN LOCK MODULE (ON STEERING COLUMN)
TRANSMISSION CONTROL MODULE
W/ HID/ AFS
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Diagnostic socket circuit (2 of 2) -> INTRUSION DETECTION MODULE
Wiring diagram intrusion detection module (3 of 4)
AUDIO HEAD UNIT
BLK/BLU WIRE
BLK/YEL WIRE
DIAGNOSTIC SOCKET
ELECTROCHROMIC MIRROR
FRONT BLOWER MOTOR CONTROL UNIT
FRONT INTERIOR LAMP
FUEL FIRED BOOSTER HEATER PUMP
GLOVE COMPARTMENT LAMP
INFORMATION, ENTERTAINMENT CONTROL MODULE
INTRUSION DETECTION MODULE
LEFT VANITY MIRROR
PARKING AID MODULE
RADIO FREQUENCY RECEIVER
RAIN SENSOR
REAR INTERIOR LAMP
REVERSE GEAR INHIBIT SOLENOID
RIGHT TAIL LAMP UNIT
RIGHT VANITY MIRROR
ROOF OPENING PANEL CONTROL MODULE
SUN ROOF SWITCH
TOUCH SCREEN DISPLAY
TRAILER ECU
TRAILER PICK-UP
TRAILER SOCKET RELAY
WHT WIRE
Go to component -> Ground distribution circuit (4 of 4) -> INTRUSION DETECTION MODULE
Wiring diagram intrusion detection module (4 of 4)
ABS MODULE
ACCELERATOR PEDAL POSITION SENSOR
AUDIO HEAD UNIT
AUXILIARY JUNCTION BOX
BATTERY BACKED SOUNDER
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRAKE PEDAL SWITCH
BRN WIRE
CEM
CENTER CONSOLE SWITCH PACK
CENTRAL JUNCTION BOX
CLIMATE CONTROL MODULE
DAB/SDARS TUNER MODULE
DIAGNOSTIC SOCKET
ELECTRIC STEERING COLUMN LOCK RELAY
ELECTRO- CHROMIC MIRROR
ENGINE CONTROL MODULE
FROM BATTERY JUNCTION BOX (DIAGRAM 1 OF 4)
FROM REAR JUNCTION BOX (DIAGRAM 1 OF 4)
FRONT FOG LAMP RELAY
FRONT WASH PUMP RELAY
FUEL FLAP LOCK RELAY
FUEL FLAP UNLOCK RELAY
FUEL PUMP RELAY
FUSE 1
FUSE 10
FUSE 11
FUSE 13
FUSE 14
FUSE 2
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 9
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HSD FET
INSTRUMENT CLUSTER
INTRUSION DETECTION MODULE
LED
LEFT INDICATOR FET
LEFT STEERING WHEEL MODULE
LIGHTING SWITCH MODULE
MAIN/ DIPPED BEAM RELAY
NAVIGATION SYSTEM MODULE
NCA WIRE
OCCUPANCY DETECTOR SENSOR
PASSENGER AIR BAG DISABLE INDICATOR
PPL
RADIO FREQUENCY RECEIVER
RAIN SENSOR
REAR POSITION LIGHT FET
REAR WASH PUMP RELAY
RED WIRE
RESTRAINTS CONTROL MODULE
REVERSE RELAY
RIGHT DIP BEAM FET
RIGHT INDICATOR FET
RIGHT REAR FOG LAMP FET
ROOF OPENING PANEL CONTROL MODULE
SCU START
SCUIN
START CONTROL UNIT (BEHIND RIGHT SIDE OF INSTRUMENT PACK)
START/ STOP SWITCH
START/STOP 1
START/STOP 2
STOP LIGHT FET
TAILGATE UNLOCK RELAY
TELEPHONE MODULE
TO BATTERY JUNCTION BOX (DIAGRAM 3 OF 4)
TO FUSE 8 (DIAGRAM 3 OF 4)
TOUCH SCREEN DISPLAY
WHT/GRN WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 4) -> INTRUSION DETECTION MODULE
