Land Rover Freelander L359 (2006-2010) wind- shield park switch Wiring diagram
This page shows the only wiring diagram for the component.wind- shield park switch, which is found in the car Land Rover Freelander L359 (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wind- shield park switch (1 of 1)
BATT A
BATT B
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
BUS -
CENTRAL ELECTRONICS MODULE (CEM)
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
DATA (-) (3)
DATA 1 (+)
DATA 2 (+)
ENGINE JUNCTION BOX
FAST WIPE
FLICK WIPE 1
FR FAST WIPE
FR PARK SIG ON/OFF
FR SLOW WIPE
FR WASH SW
FR WIPE
FR WIPE HI/LO
FRONT WASHER PUMP RELAY
FRONT/REAR SCREEN WASHER PUMP
FUSE 1
FUSE 14
FUSE 22
FUSE 8
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
INSTRUMENT CLUSTER
INTER- MITTENT
LOW WASHER FLUID IND
LOW WASHER FLUID LEVEL SENSOR
LOW WASHER LEVEL
MS MS CAN CAN
NCA WIRE
ON-OFF WIPER RELAY
PPL
PPL/ORG WIRE
PPL/WHT WIRE
RAIN SENSOR
REAR WASHER PUMP RELAY
SLOW WIPE
SLOW-FAST WIPER RELAY
STEERING COLUMN LIGHTING SWITCH
STEERING COLUMN WIPER SWITCH
STEERING WHEEL MODULE
TERMINATING RESISTOR
VARIABLE DELAY WINDSHIELD WIPER SWITCH
WASH SWITCH
WASHER PUMP
WHT WIRE
WIND- SHIELD PARK SWITCH
WINDSHIELD WIPER MOTOR
Go to component -> Front wiper/washer circuit -> WIND- SHIELD PARK SWITCH
