Land Rover Freelander L359 (2006-2010) gearshift module Wiring diagram
This page shows the only wiring diagram for the component.gearshift module, which is found in the car Land Rover Freelander L359 (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gearshift module (1 of 1)
ACTIVE ON DEMAND COUPLING MODULE
AIR QUALITY SENSOR
AUTOMATIC TEMPERATURE CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
CENTER FASCIA PACK SWITCH
DIAGNOSTIC SOCKET
FACE/FEET AIR DISTRIBUTION DOOR MOTOR
FUEL PUMP DRIVER MODULE
FUEL TANK UNIT
GEARSHIFT MODULE
HIGH MOUNTED STOP LAMP
IN-CAR TEMPERATURE SENSOR
INSTRUMENT CLUSTER
INTAKE AIR DOOR MODULE
LEFT AIR TEMPERATURE DOOR MOTOR
LEFT TAIL LAMP UNIT
LICENSE PLATE LAMP, TAIL DOOR SWITCH
OCCUPANCY DETECTOR SENSOR
PASSENGER AIR BAG DISABLE SWITCH
PTC HEATER
REAR JUNCTION BOX
REAR WINDOW HEATER ELEMENT
REAR WINDOW WIPER MOTOR
RIGHT AIR TEMPERATURE DOOR MOTOR
SCREEN AIR DISTRIBUTION DOOR MOTOR
START CONTROL UNIT
STEERING COLUMN LOCK MODULE
STEERING WHEEL MODULE
UPPER TAILGATE CDL MOTOR
YEL/VIO WIRE
Go to component -> Ground distribution circuit (3 of 4) -> GEARSHIFT MODULE
