Car Wiring Diagrams for Warning systems circuit for Land Rover Freelander L314 (2003-2006)

BLK WIRE BLU/BRN WIRE BLU/ORG WIRE CENTRAL CONTROL UNIT DOOR OPEN IND ENGINE COMPART- MENT FUSE BOX FUSE 18 FUSIBLE LINK 12 GRN WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN START OR ON INSTRUMENT PACK LEFT BUCKLE SWITCH LEFT DOOR SWITCH LEFT FRONT DOOR LOCK MOTOR LIGHTING SWITCH PASSENGER COMPARTMENT FUSE BOX PPL/BLK WIRE PPL/GRY WIRE PPL/WHT WIRE RED/PPL WIRE RED/WHT WIRE SEAT BELT IND
