Land Rover Freelander L314 (2003-2006) immobilization engine ecu Wiring diagram
This page shows the only wiring diagram for the component.immobilization engine ecu, which is found in the car Land Rover Freelander L314 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram immobilization engine ecu (1 of 1)
3 DOOR
5 DOOR
ABS ECU
AIR TEMPERATURE SENSOR
BALANCE VALVE 1
BLK WIRE
BONNET SWITCH
BUTTERFLY VALVE
COOLING FAN CONTROL UNIT
CRUISE CONTROL INTERFACE
DIGITAL CLOCK
ENGINE COMPARTMENT FUSE BOX
ENGINE COMPARTMENT FUSE BOX STARTER RELAY
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE RELAY
FUEL TANK UNIT
GLOVE BOX SWITCH
HAZARD WARNING SWITCH
HEADLAMP LEVELING SWITCH
IMMOBILIZATION ENGINE ECU
INSTRUMENT ILLUMINATION DIMMER
INSTRUMENT PACK
KNOCK SENSOR SHIELD
LEFT FRONT FOG LAMP
LEFT FRONT SIDE REPEATER LAMP
LEFT HEADLAMP
LEFT HORN
MIRROR SWITCH
NCA WIRE
PASSENGER COMPARTMENT FUSE BOX
PASSENGER SIDE DOOR MIRROR
REAR FOG GUARD LAMP SWITCH
REAR SCREEN WASHER MOTOR
REAR SCREEN WASHER SWITCH
REAR WIPER SWITCH
RIGHT FRONT DOOR LOCK MOTOR
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE REPEATER LAMP
RIGHT HEADLAMP
RIGHT HORN
RIGHT TAILLAMP UNIT
TRANSPONDER COIL
ULTRASONIC MODULE
WINDOW LIFT ECU
WINDOW LIFT SWITCH PACK
WINDSCREEN WASHER PUMP
Go to component -> Ground distribution circuit (1 of 3) -> IMMOBILIZATION ENGINE ECU
