Land Rover Freelander L314 (2003-2006) cruise control interface Wiring diagrams
This page contains all the electrical diagrams for the component. cruise control interface, in which he is found in the car Land Rover Freelander L314 (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cruise control interface (1 of 3)
3 DOOR
5 DOOR
ABS ECU
AIR TEMPERATURE SENSOR
BALANCE VALVE 1
BLK WIRE
BONNET SWITCH
BUTTERFLY VALVE
COOLING FAN CONTROL UNIT
CRUISE CONTROL INTERFACE
DIGITAL CLOCK
ENGINE COMPARTMENT FUSE BOX
ENGINE COMPARTMENT FUSE BOX STARTER RELAY
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE RELAY
FUEL TANK UNIT
GLOVE BOX SWITCH
HAZARD WARNING SWITCH
HEADLAMP LEVELING SWITCH
IMMOBILIZATION ENGINE ECU
INSTRUMENT ILLUMINATION DIMMER
INSTRUMENT PACK
KNOCK SENSOR SHIELD
LEFT FRONT FOG LAMP
LEFT FRONT SIDE REPEATER LAMP
LEFT HEADLAMP
LEFT HORN
MIRROR SWITCH
NCA WIRE
PASSENGER COMPARTMENT FUSE BOX
PASSENGER SIDE DOOR MIRROR
REAR FOG GUARD LAMP SWITCH
REAR SCREEN WASHER MOTOR
REAR SCREEN WASHER SWITCH
REAR WIPER SWITCH
RIGHT FRONT DOOR LOCK MOTOR
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE REPEATER LAMP
RIGHT HEADLAMP
RIGHT HORN
RIGHT TAILLAMP UNIT
TRANSPONDER COIL
ULTRASONIC MODULE
WINDOW LIFT ECU
WINDOW LIFT SWITCH PACK
WINDSCREEN WASHER PUMP
Go to component -> Ground distribution circuit (1 of 3) -> CRUISE CONTROL INTERFACE
Wiring diagram cruise control interface (2 of 3)
ABS ECU
ALTERNATOR/ GENERATOR
AUTOMATIC TRANSMISSION SELECTOR
BATTERY
BLU/BRN WIRE
BRAKE PEDAL SWITCH
BRN WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/PNK WIRE
BRN/RED WIRE
BRN/WHT WIRE
CAMSHAFT POSITION SENSOR
CANADA
COOLING FAN CONTROL UNIT
CRUISE CONTROL INTERFACE
CRUISE CONTROL SWITCH
ENGINE COMPARTMENT FUSE BOX
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE RELAY
EVEN-POST CATALYST OXYGEN SENSOR
EVEN-PRE CATALYST OXYGEN SENSOR
FROM BATTERY, IN ENGINE COMPT FUSE BOX (DIAGRAM 1 OF 5)
FROM FUSE 6 IN PASSENGER COMPT FUSE BOX (DIAGRAM 4 OF 5)
FUEL PUMP RELAY
FUSE 10
FUSE 3
FUSE 6
FUSE 7
FUSE LINK 1
FUSE LINK 10
FUSE LINK 11
FUSE LINK 12
FUSE LINK 3
FUSE LINK 4
FUSE LINK 5
FUSE LINK 6
FUSE LINK 8
FUSE LINK 9
GRN WIRE
HAZARD WARNING RELAY
HAZARD WARNING SWITCH
HILL DESCENT RELAY
HILL DESCENT SWITCH
HORN RELAY
INERTIA SWITCH
LIGHTING SWITCH
MAIN RELAY
MASS AIR FLOW SENSOR
ODD POST-CATALYST OXYGEN SENSOR
ODD-PRE CATALYST OXYGEN SENSOR
PASSENGER COMPARTMENT FUSE BOX
RED WIRE
RED/BRN WIRE
STARTER MOTOR
THROTTLE PEDAL SWITCH
TO FUSE 10 IN PASSENGER COMPT FUSE BOX (DIAGRAM 5 OF 5)
TO FUSE 36 IN PASSENGER COMPARTMENT FUSE BOX (DIAGRAM 2 OF 5)
TO FUSE 4 IN ENGINE COMPT FUSE BOX (DIAGRAM 2 OF 5)
TO FUSE LINK 2 IN ENGINE COMPT FUSE BOX (DIAGRAM 3 OF 5)
TO FUSE LINK 4 IN ENGINE COMPT FUSE BOX (DIAGRAM 1 OF 5)
TO IGNITION SWITCH (DIAGRAM 3 OF 5)
WHT WIRE
YEL/GRN WIRE
Go to component -> Power distribution circuit (1 of 5) -> CRUISE CONTROL INTERFACE
Wiring diagram cruise control interface (3 of 3)
AIR CON CLUTCH RELAY
AUTO ILLUM
AUTOMATIC TRANSMISSION SELECTOR
BALANCE-1 VALVE
BLK WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BRN WIRE
BRN/PNK WIRE
BRN/RED WIRE
BUTTERFLY VALVE
COMMAND SHIFT SWITCH
COOLING FAN CONTROL UNIT
CRANKSHAFT POSITION SENSOR
CRUISE CONTROL INTERFACE
ELECTRONIC AUTOMATIC TRANSMISSION ECU
ENGINE COMPARTMENT FUSE BOX
ENGINE CONTROL MODULE
ENHANCE VACUUM
FROM FUSE LINK 9 IN ENGINE COMPT FUSE BOX (DIAGRAM 1 OF 5)
FROM MAIN RELAY IN ENGINE COMPT FUSE BOX (DIAGRAM 1 OF 5)
FRONT FOG LAMP RELAY 3
FRONT FOG LAMP SWITCH
FUEL TANK PUMP
FUSE 1
FUSE 14
FUSE 2
FUSE 30
FUSE 34
FUSE 36
FUSE 4
FUSE 42
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6
ILLUMINATION RELAY
INSTRUMENT PACK
LEFT HEADLAMP
MAIN/DIPPED BEAM RELAY
NO DIMMER
PASSENGER COMPARTMENT FUSE BOX
PURGE CONTROL VALVE
REAR FOG GUARD LAMP RELAY
RIGHT HEADLAMP
TEMPERATURE E-BOX SENSOR
YEL/BLU WIRE
Go to component -> Power distribution circuit (2 of 5) -> CRUISE CONTROL INTERFACE
