Tailgate & fuel door release circuit for Land Rover Freelander II facelift (2010-2012)
Tailgate & fuel door release circuit
BATT A
BLK WIRE
BLK/GRY WIRE
BLK/PPL WIRE
BRN WIRE
BRN/GRN WIRE
CENTER INSTRUMENT PANEL SWITCH PACK
CENTRAL ELECTRONICS MODULE
CENTRAL JUNCTION BOX
DOOR LOCK TAILGATE
FUEL FLAP LOCK RELAY
FUEL FLAP RELEASE MOTOR
FUEL FLAP UNLOCK RELAY
FUEL LOCK
FUEL UNLOCK
FUSE 25
GRY/BRN WIRE
HOT AT ALL TIMES
MASTER LOCK SW
MASTER LOCK SWITCH
MASTER UNLOCK SW
MASTER UNLOCK SWITCH
NUMBER PLATE, TAIL DOOR SWITCH LAMP
TAIL DOOR RELEASE SWITCH
TAILGATE AJAR
TAILGATE RELEASE
TAILGATE UNLOCK RELAY
UPPER TAILGATE CDL MOTOR
WHT/ORG WIRE
YEL/ORG WIRE
