Car Wiring Diagrams for Steering column circuit for Land Rover Freelander II facelift (2010-2012)

BLK/PPL WIRE BLK/WHT WIRE CENTRAL ELECTRONICS MODULE (CEM) CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM ELECTRIC STEERING COLUMN LOCK RELAY FUSE 23 GRN/ORG WIRE GRY/BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LIN 1 MS CAN-H MS CAN-L PPL/BRN WIRE PPL/ORG WIRE SCL CTRL STEERING COLUMN LOCK MODULE
