Backup lamps circuit for Land Rover Freelander II facelift (2010-2012)
Backup lamps circuit
BATTERY JUNCTION BOX
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
CENTRAL ELECTRONIC MODULE (CEM)
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
FUSE 11
FUSE LINK 18
GRN/WHT WIRE
HOT AT ALL TIMES
HS CAN-H
HS CAN-L
LEFT TAIL LAMP UNIT
REVERSE LAMP
REVERSE LAMP SWITCH
REVERSE RELAY
RIGHT TAIL LAMP UNIT
WHT WIRE
WHT/BLU WIRE
YEL/RED WIRE
