Land Rover Freelander II facelift 2 (2012-2014) left steering wheel switchpack Wiring diagram
This page shows the only wiring diagram for the component.left steering wheel switchpack, which is found in the car Land Rover Freelander II facelift 2 (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left steering wheel switchpack (1 of 1)
BATTERY JUNCTION BOX
BLK WIRE
BLK/PPL WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
CENTRAL JUNCTION BOX (CJB)
CLOCK- SPRING
DRIVER AIR BAG MODULE
FUSE 51
FUSE LINK 31
FUSE LINK 33
GRN WIRE
GRY WIRE
HORN RELAY
HORN RLY
HORNS
HOT AT ALL TIMES
LEFT HORN SWITCH
LEFT STEERING WHEEL SWITCHPACK
LIN 1
NCA WIRE
RED WIRE
RIGHT HORN SWITCH
RIGHT STEERING WHEEL SWITCHPACK
STEERING WHEEL MODULE
SWS GND
WHT WIRE
WHT/RED WIRE
Go to component -> Horn circuit -> LEFT STEERING WHEEL SWITCHPACK
