Car Wiring Diagrams for Heated seats circuit for Land Rover Freelander II (2006-2010)

AIR CONDITIONING SYSTEM BLK WIRE BLK/BLU WIRE BRN WIRE BRN/PPL WIRE CAN L CLIMATE CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER HEATED SEAT MODULE DRIVER SEAT BACKREST HEATER DRIVER SEAT CUSHION HEATER DRIVER THERMISTOR (UNDER DRIVER'S SEAT) FRONT PASSENGER HEATED SEAT MODULE FRONT PASSENGER THERMISTOR (IN FRONT PASSENGER'S SEAT) GRY WIRE GRY/ORG WIRE HOT W/ IGNITION RELAY ENERGIZED IGN LEFT SEAT HEATER SWITCH LIN L LIN R PASSENGER SEAT BACKREST HEATER PASSENGER SEAT CUSHION HEATER PPL PPL/ORG WIRE REAR JUNCTION BOX RED WIRE RIGHT SEAT HEATER SWITCH WHT/GRN WIRE YEL WIRE
