Land Rover Freelander II (2006-2010) automatic temperature control module Wiring diagrams
This page contains all the electrical diagrams for the component. automatic temperature control module, in which he is found in the car Land Rover Freelander II (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
automatic temperature control module wiring diagram (1 of 2)
ACTIVE ON DEMAND COUPLING MODULE
AIR QUALITY SENSOR
AUTOMATIC TEMPERATURE CONTROL MODULE
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BLU WIRE
CENTER FASCIA PACK SWITCH
DIAGNOSTIC SOCKET
FACE/FEET AIR DISTRIBUTION DOOR MOTOR
FUEL PUMP DRIVER MODULE
FUEL TANK UNIT
GEARSHIFT MODULE
HIGH MOUNTED STOP LAMP
IN-CAR TEMPERATURE SENSOR
INSTRUMENT CLUSTER
INTAKE AIR DOOR MODULE
LEFT AIR TEMPERATURE DOOR MOTOR
LEFT TAIL LAMP UNIT
LICENSE PLATE LAMP, TAIL DOOR SWITCH
OCCUPANCY DETECTOR SENSOR
PASSENGER AIR BAG DISABLE SWITCH
PTC HEATER
REAR JUNCTION BOX
REAR WINDOW HEATER ELEMENT
REAR WINDOW WIPER MOTOR
RIGHT AIR TEMPERATURE DOOR MOTOR
SCREEN AIR DISTRIBUTION DOOR MOTOR
START CONTROL UNIT
STEERING COLUMN LOCK MODULE
STEERING WHEEL MODULE
UPPER TAILGATE CDL MOTOR
YEL/VIO WIRE
Go to component -> Ground distribution circuit (3 of 4) -> AUTOMATIC TEMPERATURE CONTROL MODULE
automatic temperature control module wiring diagram (2 of 2)
ABS MODULE
ACCELERATOR PEDAL POSITION SENSOR
AUDIO HEAD UNIT
AUTOMATIC TEMPERATURE CONTROL MODULE
BATTERY BACKED SOUNDER
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN/RED WIRE
CEM
CENTRAL JUNCTION BOX
DAB/SDARS TUNER MODULE
DIAGNOSTIC SOCKET
ELECTRIC STEERING COLUMN LOCK RELAY
ELECTRO- CHROMIC MIRROR
ENGINE CONTROL MODULE
FROM AUXILIARY JUNCTION BOX (DIAGRAM 1 OF 4)
FROM ENGINE JUNCTION BOX (DIAGRAM 1 OF 4)
FRONT FOG LAMP RELAY
FRONT WASH PUMP RELAY
FUEL FLAP LOCK RELAY
FUEL FLAP UNLOCK RELAY
FUEL PUMP RELAY
FUSE 1
FUSE 10
FUSE 11
FUSE 13
FUSE 14
FUSE 2
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 25
FUSE 26
FUSE 27
FUSE 28
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 9
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
INSTRUMENT CLUSTER
INTRUSION DETECTION MODULE
LEFT INDICATOR FET
LIGHTING SWITCH MODULE
MAIN/ DIPPED BEAM RELAY
NAVIGATION SYSTEM MODULE
OCCUPANCY DETECTOR SENSOR
OPTIMIZATION TERRAIN SWITCH
PPL
PTC HEATER
RADIO FREQUENCY RECEIVER
RAIN SENSOR
REAR JUNCTION BOX
REAR POSITION LIGHT FET
REAR WASH PUMP RELAY
RED WIRE
RESTRAINTS CONTROL MODULE
REVERSE RELAY
RIGHT DIP BEAM FET
RIGHT INDICATOR FET
ROOF OPENING PANEL CONTROL MODULE
START CONTROL UNIT
START/ STOP SWITCH
STEERING WHEEL MODULE
STOP LAMP SWITCH
STOP LIGHT FET
TAILGATE UNLOCK RELAY
TELEPHONE MODULE
TO ENGINE JUNCTION BOX (DIAGRAM 3 OF 4)
TO FUSE 8 (DIAGRAM 3 OF 4)
TOUCH SCREEN DISPLAY
WHT/GRN WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 4) -> AUTOMATIC TEMPERATURE CONTROL MODULE
