Front wiper/washer circuit for Land Rover Freelander I facelift (2003-2006)
Front wiper/washer circuit
BLK WIRE
BLU/LT GRN WIRE
BRN/LT GRN WIRE
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPT FUSE BOX)
FLICK WIPE SWITCH
FRONT WIPER RELAY
FRONT WIPER SWITCH
FUSE 1
FUSE 8
GRN WIRE
GRN/YEL WIRE
HOT IN ON
HOT IN START OR ON
INT INT LOW
INT WASHER WINDSCREEN SWITCH
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/PNK WIRE
OFF
OFF/ HIGH
PARK SWITCH
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
RED/GRN WIRE
VARIABLE WIPE
WHT/PNK WIRE
WINDSCREEN WASH/WIPE SWITCH
WINDSCREEN WASHER PUMP
WINDSCREEN WIPER MOTOR
