Power windows circuit, 5 door for Land Rover Freelander I facelift (2003-2006)
Power windows circuit, 5 door (1 of 2)
BLK WIRE
BLU WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX)
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 18
FUSE 29
FUSE 32
FUSE 33
FUSE 35
FUSE 8
FUSE LINK 4
GRN/BLU WIRE
GRN/RED WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR DOWN RELAY
LEFT REAR UP RELAY
LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR)
ORG/BLU WIRE
ORG/RED WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PASSENGER WINDOW MOTOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOWN RELAY
RIGHT FRONT UP RELAY
RIGHT REAR DOWN RELAY
RIGHT REAR UP RELAY
RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR)
TIMEOUT RELAY
WHT/BLU WIRE
WHT/RED WIRE
Power windows circuit, 5 door (2 of 2)
BLK WIRE
BLU WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY/GRN WIRE
GRY/ORG WIRE
INTERIOR LIGHTS
LEFT FRONT DOWN RELAY
LEFT FRONT DOWN SWITCH
LEFT FRONT UP RELAY
LEFT FRONT UP SWITCH
LEFT REAR SWITCH DOWN 2
LEFT REAR SWITCH UP 2
LEFT REAR WINDOW SWITCH
ORG/BLU WIRE
ORG/RED WIRE
PASSENGER DOOR WINDOW SWITCH
REAR ENABLE
RED WIRE
RED/BLK WIRE
RED/ORG WIRE
RIGHT FRONT SWITCH DOWN 2
RIGHT FRONT SWITCH UP 2
RIGHT REAR SWITCH DOWN 2
RIGHT REAR SWITCH UP 2
RIGHT REAR WINDOW SWITCH
SWITCH DOWN 1
SWITCH UP 1
SYSTEM
WHT/BLU WIRE
WHT/RED WIRE
WINDOW LIFT ECU
WINDOW LIFT PACK SWITCH
WINDOW MOTOR
