Power windows circuit, 3 door for Land Rover Freelander I facelift (2003-2006)
Power windows circuit, 3 door
BLK WIRE
BLU WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX)
DOWN
DRIVER DOOR WINDOW SWITCH
DRIVER WINDOW MOTOR
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 18
FUSE 29
FUSE 35 FUSE 8
FUSE LINK 4
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ORG/BLU WIRE
ORG/GRN WIRE
ORG/RED WIRE
ORG/YEL WIRE
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PASSENGER DOOR WINDOW SWITCH
PASSENGER WINDOW MOTOR
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
TIMEOUT RELAY
WINDOW LIFT ECU (BEHIND LEFT SIDE OF DASH)
WINDOW LIFT RELAY
