Power mirrors circuit, without fold-back mirrors for Land Rover Freelander I facelift (2003-2006)
Power mirrors circuit, without fold-back mirrors
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/PPL WIRE
BLK/YEL WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX)
DEFOGGER SYSTEM
DRIVER SIDE DOOR MIRROR
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 15
FUSIBLE LINK 4
GRN WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT DOOR MIRROR HEATER
LEFT DOOR MIRROR HORIZONTAL ADJUSTMENT MOTOR
LEFT DOOR MIRROR VERTICAL ADJUSTMENT MOTOR
MIRROR SWITCH
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PASSENGER SIDE DOOR MIRROR
RIGHT DOOR MIRROR HEATER
RIGHT DOOR MIRROR HORIZONTAL ADJUSTMENT MOTOR
RIGHT DOOR MIRROR VERTICAL ADJUSTMENT MOTOR
TIME OUT RELAY
