Horn circuit for Land Rover Freelander I facelift (2003-2006)
Horn circuit
BLK WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX)
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 6
FUSIBLE LINK 4
HORN RELAY
HOT AT ALL TIMES
J/C
LEFT HORN (LEFT FRONT OF ENGINE COMPARTMENT) LEFT HORN SWITCH
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PPL
PPL/BLK WIRE
PPL/YEL WIRE
RIGHT HORN
RIGHT HORN SWITCH
ROTARY COUPLER (AT UNDERSIDE OF STEERING COLUMN)
