Rear defogger circuit for Land Rover Freelander I facelift (2003-2006)
Rear defogger circuit
BLK WIRE
BLK/PNK WIRE
BLK/RED WIRE
BRN WIRE
BRN/GRN WIRE
CENTRAL CONTROL UNIT
COMPT FUSE BOX)
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 16
FUSE 18
FUSE 26
GRN/YEL WIRE
HEATED REAR SCREEN RELAY
HEATED REAR SCREEN SWITCH
HOT AT ALL TIMES
HOT IN START OR ON
ILLUM
J/C 0294
OIL PRESSURE SWITCH (AT LOWER FRONT OF ENGINE)
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PPL
PPL/YEL WIRE
REAR SCREEN HEATER ELEMENT
ROOF SENSING SWITCH
TAIL DOOR WINDOW SWITCH
WHT/BRN WIRE
