Mirror heater & front deicer circuit for Land Rover Freelander I facelift (2003-2006)
Mirror heater & front deicer circuit
BATTERY
BLK WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPT FUSE BOX)
DRIVER SIDE DOOR MIRROR PASSENGER SIDE DOOR MIRROR
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPT)
FUSE
FUSE 18
FUSE 3
FUSE FUSE
FUSE HOLDER (AT LEFT SIDE OF ENGINE COMPT)
GRY/BLK WIRE
HEATED FRONT SCREEN RELAY
HEATED FRONT SCREEN SWITCH ILLUM
HOT IN ON PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
HOT IN START OR ON
LEFT FRONT SCREEN ELEMENT
OIL PRESSURE SWITCH (AT LOWER FRONT OF ENGINE)
PNK/ORG WIRE
PPL/GRY WIRE
PPL/PNK WIRE
PPL/WHT WIRE
RIGHT FRONT SCREEN ELEMENT
WHT/BRN WIRE
