Cooling fan circuit for Land Rover Freelander I facelift (2003-2006)
Cooling fan circuit
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/GRN WIRE
BRN/PNK WIRE
CONDENSER FAN MOTOR
COOLING FAN CONTROL UNIT (AT LEFT SIDE OF ENGINE COMPARTMENT)
COOLING FAN MOTOR 1 (LEFT FRONT OF ENGINE COMPARTMENT)
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
ENGINE CONTROL MODULE (INSIDE E-BOX)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR (AT LEFT SIDE OF ENGINE)
FUSE 4
FUSIBLE LINK 5
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
MAIN RELAY
PNK WIRE
PNK/BLK WIRE
PNK/GRN WIRE
PPL
PPL/GRY WIRE
