Land Rover Freelander I facelift (2003-2006) Anti-lock brakes circuit

ABS ECU ABS WARNING INDICATOR ACCELEROMETER ACCELEROMETER (UNDER CENTER CONSOLE) ANTI-THEFT SYSTEM BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE FLUID LEVEL SWITCH (AT LEFT REAR OF ENGINE COMPT) BRAKE PEDAL SWITCH BRAKE PEDAL SWITCH (UNDER LEFT SIDE OF DASH) BRN/PNK WIRE BRN/RED WIRE CENTRAL CONTROL UNIT CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX) CRUISE CONTROL INTERFACE ECU CRUISE CONTROL INTERFACE ECU (UNDER PASSENGER DIAGNOSTIC SOCKET ELECTRONIC AUTOMATIC TRANSMISSION ECU ELECTRONIC AUTOMATIC TRANSMISSION ECU (INSIDE E-BOX) ENGINE COMPARTMENT FUSE BOX ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPT) ENGINE CONTROL MODULE ENGINE CONTROL MODULE (INSIDE E-BOX) FUSE 16 FUSE 2 FUSE 2 FUSE 6 FUSE 25 FUSE 6 FUSIBLE LINK 11 FUSIBLE LINK 8 GRN WIRE GRN/BLK WIRE GRN/PPL WIRE GRN/RED WIRE HILL DESCENT RELAY HILL DESCENT SWITCH HOT AT ALL TIMES HOT IN ON HOT IN ON OR START INSTRUMENT PACK LEFT FRONT ABS SENSOR LEFT FRONT ABS SENSOR (AT LOWER LEFT FRONT OF ENGINE COMPARTMENT) LEFT REAR ABS SENSOR LEFT REAR ABS SENSOR (BELOW LEFT REAR WHEELWELL) PASSENGER COMPT FUSE BOX PASSENGER COMPT FUSE BOX (BEHIND LEFT SIDE OF DASH) PNK PNK DIAGNOSTIC SOCKET (BEHIND LEFT SIDE OF CENTER CONSOLE) WIRE PNK WIRE PPL PPL/GRY WIRE RED WIRE RED/BLK WIRE RIGHT FRONT ABS SENSOR RIGHT FRONT ABS SENSOR (AT RIGHT FRONT OF ENGINE COMPARTMENT) RIGHT REAR ABS SENSOR RIGHT REAR ABS SENSOR (BELOW RIGHT REAR WHEELWELL) SEAT) TRACTION CONTROL WARNING INDICATOR W/ CRUISE W/ CRUISE W/O CRUISE W/O CRUISE WHT WIRE WHT/BLK WIRE WHT/ORG WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE
