Land Rover Freelander I facelift (2003-2006) timeout relay Wiring diagrams
This page contains all the electrical diagrams for the component. timeout relay, in which he is found in the car Land Rover Freelander I facelift (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram timeout relay (1 of 2)
BLK WIRE
BLU WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX)
DOWN
DRIVER DOOR WINDOW SWITCH
DRIVER WINDOW MOTOR
ENGINE COMPARTMENT FUSE BOX
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 18
FUSE 29
FUSE 35
FUSE 35 FUSE 8
FUSE 8
FUSE LINK 4
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ORG/BLU WIRE
ORG/GRN WIRE
ORG/RED WIRE
ORG/YEL WIRE
PASSENGER COMPARTMENT FUSE BOX
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PASSENGER DOOR WINDOW SWITCH
PASSENGER WINDOW MOTOR
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
TIMEOUT RELAY
WINDOW LIFT ECU
WINDOW LIFT ECU (BEHIND LEFT SIDE OF DASH)
WINDOW LIFT RELAY
Go to component -> Power windows circuit, 3 door -> TIMEOUT RELAY
Wiring diagram timeout relay (2 of 2)
BLK WIRE
BLU WIRE
BRN/WHT WIRE
CENTRAL CONTROL UNIT
CENTRAL CONTROL UNIT (BEHIND PASSENGER COMPARTMENT FUSE BOX)
ENGINE COMPARTMENT FUSE BOX
ENGINE COMPARTMENT FUSE BOX (LEFT REAR OF ENGINE COMPARTMENT)
FUSE 18
FUSE 29
FUSE 32
FUSE 33
FUSE 35
FUSE 8
FUSE LINK 4
GRN/BLU WIRE
GRN/RED WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR DOWN RELAY
LEFT REAR UP RELAY
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW MOTOR (IN LEFT REAR DOOR)
ORG/BLU WIRE
ORG/RED WIRE
PASSENGER COMPARTMENT FUSE BOX
PASSENGER COMPARTMENT FUSE BOX (BEHIND LEFT SIDE OF DASH)
PASSENGER WINDOW MOTOR
RED WIRE
RED/BLK WIRE
RIGHT FRONT DOWN RELAY
RIGHT FRONT UP RELAY
RIGHT REAR DOWN RELAY
RIGHT REAR UP RELAY
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW MOTOR (IN RIGHT REAR DOOR)
TIMEOUT RELAY
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Power windows circuit, 5 door (1 of 2) -> TIMEOUT RELAY
