Land Rover Freelander I facelift (2003-2006) header 0284 Wiring diagram

1 (PINS 2-6 NOT USED) 7 (PINS 8-12 NOT USED) 13 14 15 16 17 18 19 20 21 22 23 24 AIR FLOW METER AIR FLOW METER (BETWEEN AIR CLEANER HOUSING, THROTTLE BODY, ON INTAKE AIR DUCT) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/ORG WIRE BLK/PNK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/YEL WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/PNK WIRE BRN/PPL WIRE BRN/WHT WIRE CAMSHAFT POSITION SENSOR CAMSHAFT POSITION SENSOR (LOWER LEFT REAR OF ENGINE) ELECTRIC THROTTLE UNIT ELECTRIC THROTTLE UNIT (ON INTAKE MANIFOLD) ENGINE CONTROL MODULE (ECM) ENGINE CONTROL MODULE (ECM) (INSIDE E-BOX) ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR (ON LEFT SIDE OF ENGINE) FUEL INJECTORS GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLK WIRE HEADER 0284 HEATED OXYGEN SENSOR (EVEN POST- CATALYST) HEATED OXYGEN SENSOR (EVEN PRE- CATALYST) HEATED OXYGEN SENSOR (ODD POST- CATALYST) HEATED OXYGEN SENSOR (ODD PRE- CATALYST) INET AIR TEMPERATURE SENSOR INET AIR TEMPERATURE SENSOR (ON TOP REAR OF ENGINE) J/C KNOCK SENSOR KNOCK SENSOR (ON TOP CENTER OF ENGINE) LT GRN/GRY WIRE NCA WIRE ORG/GRN WIRE ORG/GRY WIRE PNK/BLK WIRE PNK/GRN WIRE WHT/BLU WIRE YEL WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/PPL WIRE YEL/RED WIRE YEL/WHT WIRE
