Driver"s memory seat circuit, 8-way for Land Rover Discovery L462 (2016-2020)

BACKREST RECLINE SEAT MOTOR BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER FORWARD/ REARWARD SEAT MOTOR DRIVER SEAT HEIGHT MOTOR DRIVER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER TILT SEAT MOTOR FUSE 28 FUSE 33 FUSE 9 GRN/BLU WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/YEL WIRE HALL EFFECT SENSOR HEIGHT MOTOR DOWN HEIGHT MOTOR SNS HEIGHT MOTOR UP HEIGHT/SLIDE SNS GND TILT/SQUAB GND TILT MOTOR SNS HOT AT ALL TIMES HOT W/ COMFORT RELAY 1 ENERGIZED HS CAN-H HS CAN-L LOGIC FEED POWER FEED 1 POWER FEED 2 POWER GND 1 POWER GND 2 PPL/GRY WIRE PPL/ORG WIRE REAR JUNCTION BOX SLIDE MOTOR (FWD) SLIDE MOTOR RWD SLIDE MOTOR SNS SQUAB MOTOR INCLINE SQUAB MOTOR RECLINE SQUAB MOTOR SNS TILT MOTOR DOWN TILT MOTOR UP YEL/ORG WIRE YEL/PPL WIRE YEL/RED WIRE

2 WAY LUMBAR BLK WIRE BRN/GRN WIRE CENTRAL JUNCTION BOX COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE DRIVER LUMBAR PUMP DRIVER SEAT MEMORY SWITCHPACK DRIVER SEAT SWITCHPACK FUSE 24 GRY WIRE GRY/PPL WIRE GRY/YEL WIRE HOT AT ALL TIMES HS CAN-H HS CAN-L LUMBAR FWD LUMBAR RWD MASSAGE MASTER SOLENOID MEM SET SW MEM STATUS LED MEMORY OUT PPL/RED WIRE STATUS ILL/IN SWITCH ILL VBATT
