Land Rover Discovery L462 (2016-2020) upstream scr nox sensor Wiring diagram
This page shows the only wiring diagram for the component.upstream scr nox sensor, which is found in the car Land Rover Discovery L462 (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram upstream scr nox sensor (1 of 1)
3.0L TURBO DIESEL
3.0L TURBO DIESEL 3.0L SC
ACTIVE GRILLE AIR SHUTTER MOTOR
AIR CONDITIONING (A/C) COMPRESSOR SOLENOID
BLK WIRE
BLOCK HEATER HARNESS TO AC MAINS SUPPLY
DEF TANK MODULE
DOWNSTREAM SCR NOX SENSOR
DOWNSTREAM SCR SOOT SENSOR
HEATED REAR WINDOW ELEMENT
HEATER BLOCK
HIGH MOUNTED STOP LAMP
LEFT REAR FOG LAMP
LEFT REAR INTERIOR LAMP
LEFT VANITY MIRROR
PPL
REAR JUNCTION BOX
REFRIGERANT SOLENOID VALVE
RIGHT BODY TAILLAMP ASSEMBLY
RIGHT REAR FOG LAMP
RIGHT REAR INTERIOR LAMP
RIGHT TAILGATE TAILLAMP ASSEMBLY
RIGHT THIRD ROW USB CHARGING SOCKET
RIGHT UPPER TAILGATE LAMP
RIGHT VANITY MIRROR
SELF LEVELING SUSPENSION (SLS) COMPRESSOR
TAILGATE CLOSING MOTOR
TAILGATE GLOBAL CLOSE SWITCH
UPPER TAILGATE CDL MOTOR
UPPER TAILGATE CONTROL MODULE
UPSTREAM SCR NOX SENSOR
VOLTAGE QUALITY MODULE
WATER IN-FUEL SENSOR
WHT/ORG WIRE
YEL/GRN WIRE
Go to component -> Ground distribution circuit (8 of 8) -> UPSTREAM SCR NOX SENSOR
