Land Rover Discovery L319 (2009-2013) unlock master switch Wiring diagram
This page shows the only wiring diagram for the component.unlock master switch, which is found in the car Land Rover Discovery L319 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unlock master switch (1 of 1)
AJAR SW
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/PPL WIRE
BODY CONTROL MODULE (BCM)
BONNET AJAR
BRN/RED WIRE
C LOCK
CENTRAL JUNCTION BOX
COMPUTER DATA LINES SYSTEM
D LOCK
DRIV AJAR
DRIVER SEAT SWITCH PACK
FUEL FLAP LOCK RELAY
FUEL FLAP RELEASE MOTOR
FUEL FLAP UNLOCK RELAY
FUSE 34
GRN/RED WIRE
HOOD SWITCH
LATCH GND
LCK SW
LEFT LOWER TAILGATE RELEASE MOTOR
LICENSE PLATE, TAILGATE SWITCH LAMP
LOCK MASTER SWITCH
LOWER TAILGATE RELEASE REQUEST SWITCH
MASTER
MS CAN-H
MS CAN-L
PASS AJAR
PASSENGER SEAT SWITCH PACK
PNK/RED WIRE
PPL/LT GRN WIRE
REL (+)
RIGHT LOWER TAILGATE RELEASE MOTOR
RIGHT REAR DOOR LOCK MOTOR
RIGHT REAR DOOR MODULE (BEHIND REAR DOOR TRIM)
RL AJAR
RR AJAR
SEC TAILGATE
SECONDARY TAILGATE RELEASE FET
TAILGATE AJAR
TAILGATE OPEN SWITCH
TAILGATE UPPER CDL MOTOR
TAILGATE)
TAILGATE/ TRUNK RELEASE FET
TRUNK REL
UNLCK SW
UNLOCK
UNLOCK MASTER SWITCH
UPPER TAILGATE RELEASE REQUEST SWITCH
WHT WIRE
WHT/ORG WIRE
YEL/BLU WIRE
YEL/PNK WIRE
YEL/WHT WIRE
Go to component -> Power door locks circuit, w/o keyless entry (2 of 2) -> UNLOCK MASTER SWITCH
