Tailgate & fuel door release circuit for Land Rover Discovery L319 (2004-2009)

BATTERY JUNCTION BOX BLK WIRE BLK/GRY WIRE BLK/PPL WIRE BLK/RED WIRE BRN/RED WIRE CENTER FACIA PACK SWITCH CENTRAL JUNCTION BOX FUEL FLAP LOCK FUEL FLAP LOCK RELAY FUEL FLAP RELEASE MOTOR FUEL FLAP UNLOCK FUEL FLAP UNLOCK RELAY FUSE 49 FUSE 50 FUSE LINK 17 GENERIC ELECTRONIC MODULE HOT AT ALL TIMES LEFT LOWER TAILGATE RELEASE MOTOR LOWER LOWER BATT 1 TAILGATE O/P LOWER TAIL DOOR RELEASE REQUEST SWITCH LOWER TAILGATE FET MASTER MASTER LOCK SWITCH MASTER LOCK UNLOCK MASTER UNLOCK SWITCH NUMBER PLATE, TAIL DOOR SWITCH LAMP PNK/GRY WIRE PNK/PPL WIRE PNK/RED WIRE RIGHT LOWER TAILGATE RELEASE MOTOR TAIL DOOR OPEN SWITCH TAIL DOOR RELEASE REQUEST TAILGATE AJAR UPPER TAIL DOOR RELEASE REQUEST UPPER TAIL DOOR RELEASE REQUEST SWITCH UPPER TAILGATE CDL MOTOR UPPER TAILGATE FET UPPER TAILGATE O/P YEL/PNK WIRE
